Product Description

• H.265/H.264 codec decoding

• Max 80Mbps incoming bandwidth

• Up to 8Mp resolution preview&playback

• Up to 1ch 8MP/4ch 1080P decoding

• HDMI/VGA simultaneous video output

• System Overview

• Dahua NVR2000-4KS2 is capable of transmitting 8MP image

• It helps to save up to 50% HDD and storage space with its H.265 decoding technology compared with H.264

• Due to its cost-effective and easy-to-install design,this NVR is ideal for a wide range of applications such as home safety,grocery,warehouse,education,and financial institutions

• The NVR is compatible with numerous third-party devices making it the perfect solution for surveillance systems that work independently of video management system (VMS)

• It features an open architecture that supports for multi-user access and is compatible with ONVIF 2.4
  protocol,enabling interoperability with IP cameras

• Functions

• High Efficiency Video Coding (H.265)

• The H.265 (ITU-T VCEG) video compression standard offers double the data compression ratio at the same level of video quality,or substantially improved video quality at the same bit rate,as compared to older video compression technologies

• H.265 offers such impressive compression by expanding the pattern comparison and difference-coding,improving motion vector prediction and motion region merging,and incorporating an additional filtering step called sample-adaptive offset filtering

• Automatic Network Replenishment (ANR) Technology

• Network Video Recorders with the ANR function automatically store video data on an IP camera SD card when the network is disconnected

• After recovery of the network,the NVR automatically retrieves the video data stored on the camera

• Easy4ip

• The Easy4ip app is available on the iOS App Store and Google Play

• It makes surveillance easy and simple,allowing you to remotely access NVR devices,view live video, receive event push notifications,and search for recorded videos from an iPhone,iPad,or Android phone at anytime from virtually anywhere

Product Specification

Brand	Dahua
Product Type	NVR
Product Model	DHI-NVR2116HS-4KS2
Product Series	Lite Series
System
Main Processor	Dual-core embedded processor
Operating System	Embedded LINUX
Audio And Video
IP Camera Input	16 channels
Two-Way Talk	1 Channel Input, 1 Channel Output, RCA
Display
Interface	1 HDMI, 1 VGA
Resolution	1920×1080, 1280×1024, 1280×720
Decoding Capacity	1ch 8MP 30fps, 4ch 1080P 30fps
Multi-Screen Display	1/4/8/9/16
OSD	Camera title, Time, Camera lock, Motion detection, Recording
Recording
Compression	H.265/H.264
Resolution	8MP/6MP/5MP/4MP/3MP/1080P/ 720P/ D1&etc
Record Rate	80Mbps
Bit Rate	16Kbps ~ 20Mbps Per Channel
Record Mode	Manual, Schedule(Regular(Continuous), MD, Stop
Record Interval	1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
Video Detection And Alarm
Trigger Events	Recording, PTZ, Tour, Video Push, Snapshot, and Screen Tips
Video Detection	Motion Detection, MD Zones: 396 (22 × 18), and Tampering
Playback And Backup
Sync Playback	1/4
Search Mode	Time /Date, MD and Exact Search (accurate to second)
Playback Function	Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Shuffle, Backup Selection, Digital Zoom
Backup Mode	USB Device/Network
Network
Interface	1 RJ-45 port (10/100/1000Mbps)
Network Function	HTTP/HTTPS, TCP/IP, IPv4/IPv6, RTSP, UDP, NTP, DHCP, DNS, IP Filter, DDNS, IP Search(Support Dahua IP camera, DVR, NVS and etc.), Easy4ip
Maximum User Access	128 users
