Product Description

• H.265/H.264 codec decoding

• Max 80Mbps incoming bandwidth

• Up to 8Mp resolution preview&playback

• Up to 1ch 8MP/4ch 1080P decoding

• HDMI/VGA simultaneous video output

• System Overview

• Dahua NVR2000-4KS2 is capable of transmitting 8MP image

• It helps to save up to 50% HDD and storage space with its H.265 decoding technology compared with H.264

• Due to its cost-effective and easy-to-install design,this NVR is ideal for a wide range of applications such as home safety,grocery,warehouse,education,and financial institutions

• The NVR is compatible with numerous third-party devices making it the perfect solution for surveillance systems that work independently of video management system (VMS)

• It features an open architecture that supports for multi-user access and is compatible with ONVIF 2.4
  protocol,enabling interoperability with IP cameras

• Function

• SMD Plus By Camera

• With intelligent algorithm,Dahua Smart Motion Detection technology can categorize the targets that trigger motion detection and filter the motion detection alarm triggered by non-concerned targets to realize effective and accurate alarm

• 4K Resolution

• 4K resolution is a revolutionary breakthrough in image processing technology

• 4K delivers four times the resolution of standard HDTV 1080p cameras and offers superior picture quality and image details

• 4K resolution improves the clarity of a magnified scene to view or record crisp forensic video from large areas

• Smart Codec
  With advanced scene-adaptive rate control algorithm,Dahua smart codec technology realizes the higher encoding efficiency than H.265 and H.264,provides high-quality video, and reduces the cost of storage and transmission

• ANR (Automatic Network Replenishment Technology)
  Video record in SD card in IP cameras when the network breaks down,and after the network recovered,the video will be transferred to device and then recorded in it

• DMSS

• The DMSS app is available on the iOS App Store and Google Play

• It makes surveillance easy and simple,allowing you to remotely access back-end devices,view live video,receive event push notifications,and search for recorded videos from an iPhone,iPad,or Android phone at anytime from virtually anywhere

Product Specification

Brand	Dahua
Product Type	NVR
Product Model	DHI-NVR2104HS-4KS2
Product Series	Lite Series
System
Main Processor	Dual-core embedded processor
Operating System	Embedded LINUX
Audio And Video
IP Camera Input	4 channels
Two-Way Talk	1 Channel Input, 1 Channel Output, RCA
Display
Interface	1 HDMI, 1 VGA
Resolution	HDMI: 3840×2160, 1920×1080, 1280×1024, 1280×720 VGA: 1920×1080, 1280×1024, 1280×720
Decoding Capacity	1ch 8MP 30fps, 4ch 1080P 30fps
Multi-Screen Display	1/4
OSD	Camera title, Time, Camera lock, Motion detection, Recording
Recording
Compression	H.265/H.264
Resolution	8MP/6MP/5MP/4MP/3MP/1080P/ 720P/ D1&etc
Record Rate	80Mbps
Bit Rate	16Kbps ~ 20Mbps Per Channel
Record Mode	Manual, Schedule(Regular(Continuous), MD, Stop
Record Interval	1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
Video Detection And Alarm
Trigger Events	Recording, PTZ, Tour, Video Push, Snapshot, and Screen Tips
Video Detection	Motion Detection, MD Zones: 396 (22 × 18), and Tampering
Playback And Backup
Sync Playback	1/4
Search Mode	Time /Date, MD and Exact Search (accurate to second)
Playback Function	Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Shuffle, Backup Selection, Digital Zoom
Backup Mode	USB Device/Network
Network
