Product Description
-
96 X 96 Panel Mount PLC with 3 Slots for IO Cards
-
3.5 Inch Graphical touch Screen Colour Display
-
4 DI on Power Supply card
-
DI, DO, AI, AO as per card selection
-
2 Channel Fast Input Upto 5 Khz
-
Power Supply :- 90 to 270 VAC/ 18 to 30 VDC
-
RTC, MODBUS and Proprietory Expansion
-
RJ25 MODBUS RS485 Slave and Master Communication port for Downloading and Communication Purpose
Product Specification
| Brand | Selec |
| Product Type | PLC |
| Product Model | FL-GT35-DI04-PS-230V-CE-RoHS |
| Description | Flexys Graphic - Power Supply Card - 230VAC, 4 Digital Inputs |
| Display Type | 3.5” LCD With Touch Screen 6 Keys (5 User Configurable) |
| Digital Inputs | 4 Digital Inputs On Power Supply Cards As Per Flexys Card Selection |
| Analog Inputs | As Per Flexys Card Selection |
| Digital Outputs | As Per Flexys Card Selection |
| Analog Outputs | As Per Flexys Card Selection |
| No Of Slots | 3 |
| RTC With Time Switch Function | Available |
| Code Memory | 256KB |
| Communication Interface | RS485 Based MODBUS RTU Protocol |
| Expansion | Yes |
| Supply Voltage | 100 to 270 VAC / 18 to 30 VDC |
| Mounting Type | Panel Mount |
| FI / Maximum Counting Frequency | FC0 (I0 & I1) & FC1 (I2 & I3) - 5KHz (on power supply card only), Normal digital inputs - 30Hz |
| Size | 99 x 99 mm |
| Warranty | As Per Manufacturer Terms and Condition |
Other Details
| Dimension (CM) - L x B x H | 9.6 x 9.6 x 6.2 |
| Unit Of Measurement | 1 Piece |
| Weight | 0.5 kg |
| Generic Type | Programmable Logic Controllers |
| Manufacturer Details | Selec Controls Pvt. Ltd. EL-27/1, Electronic Zone, TTC Industrial Area, MIDC, Mahape Navi Mumbai - 400 710, Maharashtra. Phone : 91-22-41418468 Email: [email protected] |
| Packer Details | Selec Controls Pvt. Ltd. EL-27/1, Electronic Zone, TTC Industrial Area, MIDC, Mahape Navi Mumbai - 400 710, Maharashtra. Phone : 91-22-41418468 Email: [email protected] |
| Country Of Origin | India |
